The Shure Model SCM800 is a full-featured, eight-channel microphone mixer for sound reinforcement, general audio recording, and audio-visual systems. Any low-impedance, balanced dynamic or condenser microphone, including a wireless microphone system, can be used with the SCM800 mixer.
	Each SCM800 accepts up to eight microphone- or line–level inputs and one aux-level input (two input jacks feed the same channel). Up to four SCM800 mixers can be linked to provide up to 32 input channels. Each input channel has a two-band equalizer, switchable microphone- or line-level operation, switchable 48 V phantom power, and a 1/4-inch send/receive insert jack.

Eight Channel Microphone Mixer

SCM800 Spec Sheet

SCM800 User Guide

<ul>
	<li>

			Compatible with Shure SCM410, SCM810 and FP410 automatic microphone mixers
	</li>
	<li>

			Adjustable EQ per channel: low-frequency rolloff and high-frequency shelving
	</li>
	<li>

			48 V phantom power selectable for each input
	</li>
	<li>

			Active balanced microphone- and line-level inputs and line level output
	</li>
	<li>

			Highly RF-resistant chassis and circuitry
	</li>
	<li>

			LED indication of channel clipping
	</li>
	<li>

			Linking capability for systems up to 32 microphones
	</li>
	<li>

			Two Aux-level input jacks that feed one channel
	</li>
	<li>

			Insert jack on each channel
	</li>
	<li>

			Manual mixing of input channels
	</li>
	<li>

			Internal Modification permits 230 V operation (SCM800) or 120 V operation (SCM800E)
	</li>
	<li>

			Front-panel headphones output with level control
	</li>
	<li>

			Peak-responding output limiter with selectable thresholds and LED indicator
	</li>
</ul>

Corporate

Education

Non-automatic version of SCM810 features adjustable channel EQ and linking capability for up to 32 mics.

TV/Film & ENG

Sound Reinforcement

Mixing & Digital Signal Processing

8-channel microphone mixer offers compatibility with any low-impedance, balanced microphone, including wireless microphone systems. Includes adjustable EQ, phantom power LED, manual mixing, and peak-responding output limiter.

SCM800

SCM800, SCM 800

8-Channel Microphone Mixer, BLOCK Connector

This eight-channel automatic mixer features the Shure&nbsp;IntelliMix&reg;, which activates only microphones being addressed, minimizing poor audio caused by multiple open microphones.

The SCM810 is designed specifically for installed sound applications.&nbsp;

Features include adjustable EQ per channel, 48 V phantom power, active balanced microphone - or line-level inputs, line-level outputs, highly RF resistant chassis and circuitry, complete logic control of microphone activation, linking capacity for up to 400 microphones, with an internal power supply. 120/230 Vac power.

Eight Channel Automatic Mixer

SCM810 Brochure

SCM810 User Guide

SCM810 Spec Sheet

SCM810 CAD

<ul>
	<li>Eight balanced mic-line input channels (Phoenix block connectors)</li>
	<li>One unbalanced 1/4&quot; aux level input</li>
	<li>Eight unbalanced 1/4&quot; direct line level outputs</li>
	<li>One balanced master line level output (Phoenix block connector)</li>
	<li>Selectable 46V phantom power per channel</li>
	<li>Level selectable peak output limiter</li>
	<li>Full rack width (single rack height)</li>
</ul>

&nbsp;

The recognized standard in automatic mixing. A great solution for recording meetings.

Conference

8-channel automatic mixer improves audio quality in any application in which multiple microphones are required. Features include fast microphone selection, adjustable EQ, adjustable low-frequency roll off, and peak-responding output limiter.

SCM810

SCM810, SCM 810

8-Channel Automatic Mixer, BLOCK Connector

Filter by product category, then series

Find a Dealer Near You

Please Choose a Country to See Available Dealers

Filter by dealer type

- Shure USA

Cable Length

Colors

Connector

Select a Combination

Frequency Band

Find my frequency

Furnished Cables

Furnished Capsules

Studio Kit

On Off Switch

Shape

Stand Type

Release Title

Viewing this video may result in cookies being placed by the vendor of the video platform to which you will be directed. Given the refusal of the deposit of cookies that you have expressed, in order to respect your choice, we have blocked the playback of this video. If you want to continue and play the video, you must give us your consent by clicking on the button below.

3 Pin XLR

Use the Shure RKC800 XLR Connector Kit to connect XLR and phono pin connectors to Shure SCM810 and SCM800 Microphone Mixers.

RKC800

XLR Connector Kit

XLR connector kit connects XLR and phonograph pin connectors to SCM810 and SCM800 Microphone Mixers.

RKC800
